Specification
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 1 |
Industrial Interfaces | |
| Profibus DP Version | 1 |
Supported Protocols | |
| Industrial Protocols | Modbus RTU slave, Modbus RTU master, Modbus ASCII slave, Modbus ASCII master, Profibus slave |
LED / Controls | |
| LED | READY LED, TX LED, RX LED, PWR1, PWR2, PROFIBUS Status LED |
| Setup of Operation Mode | Console Port, By Switches |
| Controls | 1xReset |
System Power Input | |
| Redundant power input | Yes |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 36 mm |
| Depth | 140 mm |
| Height | 105 mm |
Connectors | |
| Connectors | Console Port RS-232 (RJ-45), DC input (terminal block) |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | EN 55022, FCC Part 15 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024 |
| Freefall | IEC 60068-2-32 |
| Safety | UL 60950-1, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
