Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| Isolation of COM Ports | 2 kV (RS-232/422/485) |
Supported Protocols |
| Industrial Protocols | EtherNet/IP adapter, EtherNet/IP scanner, Modbus TCP server, Modbus TCP client, Modbus RTU slave, Modbus RTU master, Modbus ASCII slave, Modbus ASCII master, MQTT client, EtherNet/IP, Modbus TCP, MQTT |
Digital Output |
| Total channels of digital output | 1 |
LED / Controls |
| LED | 10/100M LED, READY LED, PWR1, PWR2, COM-ports LED |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
| Controls | 1xReset |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 36 mm |
| Depth | 140 mm |
| Height | 105 mm |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Explosion safety | IECEx |
| Freefall | IEC 60068-2-32 |
| Oil And Gas | ATEX Zone 2 Ex nC IIC, UL/cUL Class I Division 2 Groups A/B/C/D |
| Safety | UL 508, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
