Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| Isolation of COM Ports | 2 kV (RS-232/422/485) |
Industrial Interfaces |
| CAN Port | 1 |
Supported Protocols |
| Industrial Protocols | EtherNet/IP adapter, EtherNet/IP scanner, PROFINET slave, Modbus TCP server, Modbus TCP client, Modbus RTU slave, Modbus RTU master, Modbus ASCII slave, Modbus ASCII master, J1939 |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, Telnet, UDP, DNS, NTP, ARP, DHCP Client, TCP/IP |
System Power Input |
| Input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 46 mm |
| Depth | 105 mm |
| Height | 134 mm |
Standards and Certifications |
| Certifications | CISPR 22 Class A, FCC Class B |
| EMI | CISPR 22 Class, FCC Part 15 Subpart B Class B |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Explosion safety | IECEx, ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Freefall | IEC 60068-2-32 |
| Oil And Gas | Class I Div.2 Groups A, B, C, D, ATEX Zone 2 Ex nC IIC |
| Safety | EN 60950-1, UL 61010-2-201 |
| Automotive | FCC Class B |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-64 |
