Specification
Ethernet | |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| Isolation of COM Ports | 2 kV (RS-232/422/485) |
Supported Protocols | |
| Industrial Protocols | Modbus RTU master, Modbus ASCII master, EtherCAT slave |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, UDP, DNS, ARP, DHCP Client, TCP/IP, SNMP Trap, Telnet, DHCP |
| Security Protocols | HTTPS |
LED / Controls | |
| Setup of Operation Mode | Web-interface |
System Power Input | |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 5-95% |
| MTBF | 2305846 h |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount, Wall |
| Protection Level of Chassis | IP30 |
Dimensions and weight | |
| Width | 45.8 mm |
| Depth | 105 mm |
| Height | 134 mm |
Standards and Certifications | |
| EMI | CISPR 32, FCC Part 15 Subpart B Class A |
| EMS | EN 61000-6-2, EN 61000-6-4 |
| Freefall | IEC 60068-2-32 |
| Safety | IEC 62443-4-2, EN 60950-1, EN 61010-2-201 |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-64 |
