Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, Desktop |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Skylake |
| Socket | LGA1151 |
| CPU Support Type | Core i3, Core i5, Core i7, Pentium |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | VGA, DVI |
Ethernet | |
| Controller Type | Intel i219-LM |
| Total Ethernet | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 9 |
| USB 2.0 | 1 |
| USB v3.x | 8 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| SATA 3 | 1 |
| mSATA | 1 |
| CFast Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| Mini-PCIe/Mini Card | 2 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | Mic In, Line Out, CFast slot, DB15 VGA, 6xDB9, 8xUSB, DVI |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10, Windows 10, Windows 8.1, Windows 7, Linux OS |
Dimensions and weight | |
| Width | 77 mm |
| Height | 192 mm |
| Depth | 230 mm |
Operating Conditions | |
| Operating Temperature | -10...40 °C |
| Vibration | With SSD: 3 Grms @ 5 ~ 500 Hz. random. 1 hr/axis |
| Shock | With SSD: 20G. IEC-68-2-27. half-sine wave. 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Safety | CCC, BSMI, UL |
