Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7, Pentium, Core i9 |
Chipset | |
| Chipset | Intel W480E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Intel i210-IT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 4 |
| RS-232/422/485 | 2 |
| USB Total | 8 |
| USB v3.x | 8 |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
| mSATA | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, HDMI, 2xRJ45 Ethernet, 8xUSB, Line In, Line Out, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Software | |
| Operating System Compatibility | Linux OS, Windows IoT Enterprise 10, Windows 10 |
Dimensions and weight | |
| Width | 77 mm |
| Height | 192 mm |
| Depth | 230 mm |
Operating Conditions | |
| Operating Temperature | -10...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
