System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| СPU Generation/Family | Skylake, Kaby Lake |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| Maximum Memory | 64 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | DisplayPort, DVI-D, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps, Intel i219-LM |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 11 |
| USB 2.0 | 5 |
| USB v3.x | 6 |
Audio | |
| Audio Controller | Realtek ALC662 |
Extension Slots | |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| PCI Express x1 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 1x4-pin RS-422/485, 4x10-pin RS-232 |
| Connectors | PS/2 Keyboard/Mouse, 10xUSB, USB type A, Console port RS-232 (4-pin), Console Port RS-232 (DB9M) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
