Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Panel |
| Protection Level of Chassis | IP22 |
| Type | Fanless |
Display |
| Display Type | LCD MVA |
| Diagonal | 24 " |
| Aspect Ratio | 16:9 |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 5000~1 |
CPU |
| Processor Installed | Intel Core i7-2610UE |
Chipset |
| Chipset | Intel HM65 |
Memory |
| Socket Type | 1xSODIMM 204pin |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic |
| Graphic Controller | Integrated in Chipset |
Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 4 |
Storage Cage |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
LED / Controls |
| LED | 1xHDD LED, Power LED, 100M LED, 1000M LED |
| Controls | KeyPad |
Connectors |
| Connectors | DVI-D, DB15 VGA, 2xPS/2, 8xNMEA Port |
System Power Input |
| Power Consumption | 75 W |
Software |
| Operating System Compatibility | Windows XP Embedded, Windows Embedded Standard 7, Windows 7 Professional, Windows XP SP3 |
Dimensions and weight |
| Width | 595 mm |
| Height | 393 mm |
| Depth | 75 mm |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class B |
| EMS | EN 55024-4-2, EN 55024-4-3, EN 55024-4-4 |
| Marine grade | DNV, IACS-E10, IEC 60945 4th, IEC 61174 |
| Safety | CCC, UL 60950-1 |
