Ethernet | |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 4 |
| SFP 100/1000 Mbit Ports | 24 |
| 10 Gbit SFP+ Ports | 4 |
Supported Protocols | |
| Managment Protocols | TFTP |
| Reservation protocols | STP, RSTP, MSTP |
| IEEE Standard | IEEE 802.1D-2004 for Spanning Tree Protocol, IEEE 802.1P for Class of Service, IEEE 802.1Q for VLAN Tagging, IEEE 802.1W for Rapid Spanning Tree Protocol, IEEE 802.3u for 100BaseT(X) and 100BaseFX, IEEE 802.3z for 1000BaseSX/LX/LHX/ZX, IEEE 802.3az for Energy-Efficient Ethernet, IEEE 802.3ah OAM for Link-Fault Management |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
Dimensions and weight | |
| Width | 43.5 mm |
| Depth | 250 mm |
| Height | 440 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
