Construction | |
| Construction Chassis | Rubber |
| Mounting Configuration | Wall VESA 75 |
| Protection Level of Chassis | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 1024x600 Dots |
| Brightness | 500 Cd/m2 |
Touch Screen | |
| Touch Screen Type | Capacitive |
CPU | |
| Processor Installed | ARM Cortex A7 |
| Max CPU frequency | 1.3 GHz |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 2 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Wi-Fi | |
| Wi-Fi Standard | 802.11a/b/g/n |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB 2.0 | 2 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| SIM Card slots | Micro-SIM |
Antenna characteristics | |
| Cellular interfaces | 4G |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | RJ45 Ethernet, 2xUSB, Mic In, Line Out, DB15 CAN Bus, Micro-SIM card slot |
System Power Input | |
| Input Voltage DC | 9...36 V |
Dimensions and weight | |
| Width | 220 mm |
| Height | 152 mm |
| Depth | 40 mm |
Operating Conditions | |
| Operating Temperature | -30...60 °C |
| Vibration | MIL-STD-810G. Method 514.7 c2/c3/c4 |
| Shock | MIL-STD-810G. 40G at 11ms Terminal / Sawtooth |
Standards and Certifications | |
| Certifications | CE, FCC |
| MIL-STD-810 | MIL-STD-810F Test Method 514.5C-2 Vibration |
| Vehicle | E-Mark |
