Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | Panel |
| Protection Level of Chassis | IP65 |
Display | |
| Display Type | LCD TFT |
| Diagonal | 7 " |
| Maximum resolution | 800x480 Dots |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 500~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
Memory | |
| Default on Board Memory | 0.13 GB |
Installed drive | |
| Flash Memory Capacity | 128 MB |
Ethernet | |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 2 |
| RS-485 | 1 |
| RS-232/485 | 1 |
| USB Total | 1 |
Software | |
| Development Software | EasyBuilder Pro |
| Operating System Installed | Special |
System Power Input | |
| Input Voltage DC | 24...24 V |
Dimensions and weight | |
| Width | 200 mm |
| Depth | 35 mm |
| Height | 146 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
Standards and Certifications | |
| Certifications | CE |
| Oil And Gas | UL/cUL Class I Division 2 Groups A/B/C/D |
