Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i7-6600U, Intel Core i3-6100U |
| Max CPU frequency | 2.6 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| USB Total | 4 |
| USB 2.0 | 1 |
| USB v3.x | 3 |
Industrial Interfaces | |
| CAN Port | 1 |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| CFast Slots | 1 |
Storage Cage | |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| SIM Card slots | 3 |
Additional Functions | |
| GPS | GPS |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, DC input (terminal block), CAN (terminal block) |
System Power Input | |
| Input Voltage DC | 9...36 V |
Power Supply | |
| Type of Power Supply | Li-battery Pack, Direct current |
Dimensions and weight | |
| Width | 260 mm |
| Height | 176 mm |
| Depth | 50 mm |
Operating Conditions | |
| Operating Temperature | -30...50 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Automotive | e13 Mark, FCC Class A |
