MVS-5603

Ціна за запитом
Embedded server Support 6th Gen. Intel Core i3/i7 CPU, 2GB DDR3L, VGA,HDMI, 2xGbit LAN, 8xGbit PoE LAN, 3xCOM, 4xUSB, 2x2.5" SATA HDD Bay, CFast, CAN, 3xMini-PCIe, VIOB-GPS-02 module, 9..36V DC-In

Specification

Construction

Construction ChassisAluminium Chassis
Mounting ConfigurationBuilt-in, Desktop
TypeFanless

CPU

CPU Support TypeCore i7, Core i3
Max CPU frequency2.6 GHz

Memory

Form-factorDDR3L
Default on Board Memory2 GB
Maximum Memory32 GB
AssemblyRemovable

Graphic

Graphic ControllerIntegrated in CPU

Ethernet

Total Ethernet8

Interfaces

COM Total3
RS-2322
RS-4221
RS-232/422/4852
USB Total4
USB 2.01
USB v3.x3

Industrial Interfaces

CAN Port1

Audio

Audio ControllerIntel HD Audio

Drive interfaces

CFast Slots1

Storage Cage

2.5" Cage Intenal1

Extension Slots

SIM Card slots3

Additional Functions

GPSGPS

Connectors

ConnectorsDB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB, Mic In, Line In, 6xM12, DC input (terminal block), CAN (terminal block)

System Power Input

Input Voltage DC9...36 V

Power Supply

Type of Power SupplyLi-battery Pack, Direct current

Dimensions and weight

Width260 mm
Height176 mm
Depth50 mm

Operating Conditions

Operating Temperature-30...50 °C

Standards and Certifications

CertificationsCE, FCC Class A
Automotivee13 Mark, FCC Class A

Files

Documentation

📄 MVS-5603-Datasheet
