Construction | |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom D510 |
| Socket | CPU onboard |
| Max CPU frequency | 1.66 GHz |
Chipset | |
| Chipset | Intel ICH8M |
Memory | |
| Form-factor | DDR2 |
| ECC | No |
| Default on Board Memory | 2 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel 82574L 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 4 |
Digital Input-Output | |
| Channels of DIO | 24 |
Digital Input | |
| Isolation DIO | Yes |
Drive interfaces | |
| CompactFlash Slots | 1 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| PCI Express x1 | 1 |
| PCI | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DVI-D, DB15 VGA, PS/2 Mouse, PS/2 Keyboard, 2xRJ45 Ethernet, 4xUSB, Audio Out, Mic In, External SATA, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 9...32 V |
Dimensions and weight | |
| Width | 118 mm |
| Height | 183 mm |
| Depth | 219 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | NaN.NaN.NaN.NaN.NaN.NaN |
| Shock | NaN.NaN.NaN.NaN.NaN |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
