Construction | |
| Mounting Configuration | Wall |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core 2 Duo P8400 |
| Socket | CPU onboard |
| Max CPU frequency | 2.26 GHz |
Chipset | |
| Chipset | Intel GM45 + ICH9M |
Memory | |
| Form-factor | DDR3 |
| ECC | No |
| Default on Board Memory | 4 GB |
| Maximum Memory | 4 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in Chipset |
Ethernet | |
| Controller Type | Intel 82574L 10/100/1000 Mbps, Realtek 8111C |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| COM Total | 4 |
| RS-232 | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
| USB 2.0 | 6 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 4xDB9, DVI-I, 4xRJ45 Ethernet, 6xUSB, DC input (terminal block) |
System Power Input | |
| Input Voltage DC | 24...24 V |
Software | |
| Operating System Compatibility | Windows XP, Windows 7, Linux OS |
Dimensions and weight | |
| Width | 248 mm |
| Height | 85 mm |
| Depth | 185 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Vibration | CF/SSD: Operating. 5 Grms. 5-500 Hz. 3 axes |
| Shock | CF/SSD: Operating. 50 G. half sine 11 ms duration |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Marine grade | IEC 60945 4th |
