Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 1 U |
| Type | Fans |
CPU | |
| СPU Generation/Family | Comet Lake |
| Socket | LGA1200 |
| CPU Support Type | Core i3, Core i5, Core i7, Core i9, Xeon |
Chipset | |
| Chipset | Intel W480E |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDIMM |
| ECC | Yes |
| Maximum Memory | 128 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | VGA |
Ethernet | |
| Controller Type | Intel i350 |
| Total Ethernet | 10 |
| 10/100/1000 Mbit/s | 10 |
Interfaces | |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| M.2 | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage Intenal | 2 |
Extension Slots | |
| Total | 4 |
| PCI Express x8 | 1 |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | Nano SIM |
LED / Controls | |
| LED | LED Bar, 1xHDD LED, Power LED, LNK/ACT LED, BYPASS LED |
| Controls | Control Buttons |
| Setup of Operation Mode | Console Port |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 8xRJ45, 2xUSB, 2xSFP, Console Port RS-232 (RJ-45) |
Power Supply | |
| Type of Power Supply | Redundant |
| Output Power | 400 W |
| Quantity of Power Modules | 2 |
Dimensions and weight | |
| Width | 430 mm |
| Height | 44 mm |
| Depth | 450 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
