Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
| Height | 2 U |
CPU | |
| СPU Generation/Family | Skylake, Cascade Lake |
| Socket | LGA 3647-P0 |
| CPU Support Type | Xeon |
| Number of CPU | 2 |
Chipset | |
| Chipset | Intel C621 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 12xDIMM |
| ECC | Yes |
| Maximum Memory | 384 GB |
| Assembly | Removable |
Ethernet | |
| Controller Type | Intel i210 |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| USB Total | 2 |
| USB v3.x | 2 |
Drive interfaces | |
| mSATA | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Extension Slots | |
| PCI Express x8 | 2 |
LED / Controls | |
| LED | LED Bar |
| Controls | Control Buttons |
Connectors | |
| Connectors | DB15 VGA, 3xRJ45 Ethernet, 2xUSB, RJ45 (Console) |
Power Supply | |
| Type of Power Supply | Redundant, 2U |
| Output Power | 800 W |
Software | |
| Operating System Compatibility | Linux OS |
Dimensions and weight | |
| Width | 430 mm |
| Height | 88 mm |
| Depth | 562 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
