System Architecture | |
| Form Factor | PC/104 |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Vortex86DX2 |
| Max CPU frequency | 0.5 GHz |
Chipset | |
| Chipset | Vortex86 System-on-Chip |
Memory | |
| Form-factor | DDR2 |
| Default on Board Memory | 0.25 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | LVDS, LCD, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 4 |
| RS-232/485 | 4 |
| USB Total | 4 |
| USB 2.0 | 4 |
Audio | |
| Audio Controller | Realtek ALC262 |
Drive interfaces | |
| SD Slots | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 6.0, Windows XP, Windows XP Embedded, Linux OS, Windows CE 7.0, X-LINUX |
Dimensions and weight | |
| Width | 96 mm |
| Length | 90 mm |
Operating Conditions | |
| Operating Temperature | -20...70 °C |
