System Architecture | |
| Form Factor | Nano-ITX |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Celeron N3160 |
| Max CPU frequency | 2.24 GHz |
Chipset | |
| Chipset | Intel Braswell SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel Gen.8 Graphics Engine |
| Interfaces | DisplayPort, LVDS, VGA-CRT |
Ethernet | |
| Controller Type | Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 3 |
| USB 2.0 | 1 |
| USB v3.x | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| M.2 | 1 |
Additional Functions | |
| Watchdog timer type | Hardware |
Connectors | |
| Connectors | 2xRJ45 Ethernet, 2xUSB, Audio Out, DC Input, Display Port |
Dimensions and weight | |
| Width | 120 mm |
| Length | 120 mm |
Operating Conditions | |
| Operating Temperature | 0...55 °C |
Standards and Certifications | |
| Certifications | CE/FCC |
