System Architecture | |
| Form Factor | Nano-ITX |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom E3930 |
| Max CPU frequency | 1.8 GHz |
| Number of CPU | 1 |
Memory | |
| Form-factor | DDR3L |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel Gen9 Graphic engine |
| Interfaces | DisplayPort, LVDS |
Ethernet | |
| Controller Type | Intel i210-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Audio | |
| Audio Controller | Realtek ALC892 |
Drive interfaces | |
| mSATA | 1 |
| MicroSD | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | 8-pin GPIO, 2xUSB 3.0 |
| Connectors | RJ45, 2xRJ45 Ethernet, 2xUSB |
Dimensions and weight | |
| Width | 120 mm |
| Length | 120 mm |
Operating Conditions | |
| Operating Temperature | -40...85 °C |
