System Architecture | |
| Form Factor | EPIC |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | AMD G-Series GX-210HA |
| Socket | CPU onboard |
| Max CPU frequency | 1 GHz |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | 2xLVDS, HDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 6 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Realtek ALC892 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB15 VGA, HDMI, 2xRJ45 Ethernet, 4xUSB |
Dimensions and weight | |
| Width | 165 mm |
| Length | 115 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
