System Architecture | |
| Form Factor | EPIC |
Construction | |
| Type | Fanless |
CPU | |
| CPU Support Type | AMD |
| Processor Installed | AMD G-Series T40E |
| Socket | CPU onboard |
| Max CPU frequency | 1.5 GHz |
| Number of CPU | 1 |
Memory | |
| Form-factor | DDR3, DDR3L |
| Socket Type | 1xSODIMM |
| Maximum Memory | 8 GB |
| Assembly | Removable |
Graphic | |
| Interfaces | LVDS, HDMI, VGA |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 6 |
| USB v3.x | 2 |
Audio | |
| Audio Controller | Realtek ALC662 |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 1 |
| Mini-PCIe/Mini Card | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Internal Ports | SATA 3, USB 2.0, 10-pin DIO, TPM, 1x4-pin RS-422/485, 10-pin RS-232, 16-pin LVDS, 10-pin Audio, HDMI, 10-pin VGA, USB 3.0 |
| Connectors | DC Input |
Software | |
| Operating System Compatibility | MS DOS, Windows 7, Linux OS |
Dimensions and weight | |
| Width | 115 mm |
| Length | 165 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
