System Architecture | |
| Form Factor | EPIC |
Construction | |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i3-6100U |
| Socket | CPU onboard |
| Max CPU frequency | 2.3 GHz |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel Skylake SoC |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 32 GB |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | LVDS, 2xHDMI, iDP |
Ethernet | |
| Controller Type | Intel i219-LM, Intel i219-IT |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 3 |
| RS-232 | 2 |
| RS-232/422/485 | 1 |
| USB Total | 7 |
| USB 2.0 | 3 |
| USB v3.x | 4 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC662 HD |
Drive interfaces | |
| mSATA | 1 |
Extension Slots | |
| Total | 2 |
| SIM Card slots | 1 |
| Mini-PCIe/Mini Card | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 2xHDMI, 2xRJ45 Ethernet, 4xUSB |
Dimensions and weight | |
| Width | 115 mm |
| Length | 165 mm |
Operating Conditions | |
| Operating Temperature | -20...60 °C |
