Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Atom x7-E3950 |
| Max CPU frequency | 2 GHz |
Chipset | |
| Chipset | Intel Atom SoC |
Memory | |
| Form-factor | DDR3L |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 16 GB |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Extension Slots | |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Connectors | |
| Connectors | DB9, HDMI, 2xUSB, Display Port |
System Power Input | |
| Input Voltage AC | 100...240 V |
| Power Consumption | 65 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 259 mm |
| Height | 21 mm |
| Depth | 147 mm |
Operating Conditions | |
| Operating Temperature | -10...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
