Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop |
| Type | Fanless |
CPU | |
| Processor Installed | Intel Core i3-6100U |
| Max CPU frequency | 2.3 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 2xSODIMM |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Ethernet | |
| Total Ethernet | 1 |
| 10/100/1000 Mbit/s | 1 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 4 |
| USB v3.x | 4 |
Storage Cage | |
| Number Of Cage External | 1 |
| 2.5" Cage Intenal | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | DB9, HDMI, RJ45 Ethernet, 4xUSB, Audio (in/out/Mic), DC Input, 1xMini DisplayPort |
System Power Input | |
| Input Voltage DC | 19...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 65 W |
Software | |
| Operating System Compatibility | Windows 7, Windows Embedded Standard 7, Windows 8, Windows Embedded Standard 8, Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 167 mm |
| Height | 55 mm |
| Depth | 139.6 mm |
Operating Conditions | |
| Operating Temperature | 0...40 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
