Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Built-in, Desktop, Panel |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel Q670E |
Memory | |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Total Ethernet | 3 |
| 10/100/1000 Mbit/s | 1 |
| 2,5 Gbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 4 |
| RS-232 | 3 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
Extension Slots | |
| Total | 4 |
| M.2 | 4 |
Connectors | |
| Connectors | 4xDB9, 3xRJ45 Ethernet, 8xUSB, Mic In, Line Out, SIM Card Slot, 4-pin DC input, 3xHDMI |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 120 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 238 mm |
| Height | 67.29 mm |
| Depth | 192 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
