Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Tiger Lake |
| Socket | FCBGA 1449 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel Iris Xe Graphics, Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i219-LM, Intel i225V |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 8 |
| USB 2.0 | 5 |
Extension Slots | |
| M.2 | 2 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 4xUSB, Mic In, Line Out, 4-pin DC input, 4xHDMI |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 96 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 190 mm |
| Height | 51.1 mm |
| Depth | 165 mm |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
