Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces |
| COM Total | 1 |
| RS-422/485 | 1 |
Digital Input |
| Total channels of digital input | 4 |
Digital Output |
| Total channels of digital output | 4 |
Supported Protocols |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, HTTP, Telnet, TCP, UDP, DHCP, ARP |
| Security Protocols | ICMP |
LED / Controls |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors |
| Connectors | Console port RS-232 (4-pin) |
System Power Input |
| Input Voltage DC | 5...5 V |
Operating Conditions |
| Operating Temperature | 0...55 °C |
Construction |
| Construction Chassis | Open Frame |
| Mounting Configuration | Built-in |
Dimensions and weight |
| Width | 40 mm |
| Height | 57 mm |
Standards and Certifications |
| Certifications | CE, WEEE, FCC |
| EMI | FCC Part 15 Subpart B Class A, EN 55022 Class B |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024 |
