Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Celeron N3350 |
| CPU Support Type | Pentium |
| Max CPU frequency | 2.4 GHz |
Memory | |
| Form-factor | DDR3L |
| ECC | No |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 500 |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| RS-232/422/485 | 1 |
| USB Total | 2 |
| USB v3.x | 2 |
Extension Slots | |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
| SIM Card slots | 1 |
Connectors | |
| Connectors | DB9, 2xHDMI, 2xRJ45 Ethernet, 2xUSB, DC Input |
System Power Input | |
| Input Voltage DC | 19...19 V |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 45 W |
Software | |
| Operating System Compatibility | Windows IoT Enterprise 10 |
Dimensions and weight | |
| Width | 152 mm |
| Height | 37.5 mm |
| Depth | 108 mm |
Operating Conditions | |
| Operating Temperature | -5...50 °C |
Standards and Certifications | |
| Certifications | FCC Class A |
| EMS | EN 55024, EN 55032 |
