Construction | |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake |
| Processor Installed | Intel N97 |
| Socket | FCBGA1264 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Socket Type | 1xSODIMM |
| ECC | No |
| Maximum Memory | 16 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Intel UHD Graphics |
Ethernet | |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 7 |
| USB 2.0 | 3 |
Extension Slots | |
| Total | 2 |
| M.2 | 1 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | DB9, 2xHDMI, 2xRJ45, 4xUSB, DC Input |
Power Supply | |
| Type of Power Supply | External power adapter AC/DC |
| Output Power | 60 W |
Software | |
| Operating System Compatibility | Windows 10, Linux kernel 4.x, Windows 11 |
Dimensions and weight | |
| Width | 179.5 mm |
| Height | 37 mm |
| Depth | 106 mm |
Operating Conditions | |
| Vibration | - Random: 2Grms @ 5~500 Hz. IEC60068-2-64 - Sinusoidal: 2G @ 5~500 Hz. IEC60068-2-6 |
| Shock | 50G peak acceleration. 11ms according to IEC60068-2-27 |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMS | EN 55032, EN 55035 |
| Safety | EN 62368-1 (LVD) |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
