Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake |
| Socket | LGA1700 |
| CPU Support Type | Core i3, Core i5, Core i7 |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR5 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel Iris Xe Graphics |
| Interfaces | DisplayPort, HDMI |
Ethernet | |
| Controller Type | Intel i225LM, Intel i225V |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 7 |
| USB 2.0 | 1 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 1 |
| M.2 | 1 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | HDMI, 2xRJ45, 4xUSB, Display Port |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Linux OS, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 190 mm |
| Height | 59.8 mm |
| Depth | 150 mm |
Operating Conditions | |
| Operating Temperature | 0...50 °C |
| Humidity | 10-95% |
Standards and Certifications | |
| Certifications | CE |
