Construction | |
| Construction Chassis | Metal Chassis |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake |
| Processor Installed | Intel Core i3-12300HE |
| Socket | CPU onboard |
| CPU Support Type | Core i3, Core i5, Core i7 |
| Max CPU frequency | 4.4 GHz |
Chipset | |
| Chipset | Intel SoC |
Memory | |
| Form-factor | DDR5 |
| Socket Type | 2xSODIMM |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel Iris Xe Graphics |
| Interfaces | HDMI, DisplayPort |
Ethernet | |
| Controller Type | Intel i225V, Intel i225LM |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| USB Total | 7 |
| USB 2.0 | 1 |
| USB v3.x | 6 |
Drive interfaces | |
| M.2 | 1 |
Extension Slots | |
| Total | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2230 E |
Connectors | |
| Connectors | HDMI, Display Port, 4xUSB, 2xRJ45 Ethernet, USB type C, DC Input |
System Power Input | |
| Input Voltage DC | 12...12 V |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | Windows 10, Windows 11, Linux OS |
Dimensions and weight | |
| Width | 183 mm |
| Height | 47.9 mm |
| Depth | 137.9 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE |
