System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| СPU Generation/Family | Skylake |
| CPU Support Type | Core i3, Core i5, Core i7, Pentium, Celeron |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q170 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDDR4 DIMM 288pin |
| ECC | No |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | 2xHDMI, DVI-I |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 14 |
| USB 2.0 | 4 |
| USB v3.x | 10 |
Digital Input-Output | |
| Channels of DIO | 8 |
Drive interfaces | |
| SATA 3 | 6 |
| RAID Levels | 0, 1, 5, 10 |
Extension Slots | |
| Total | 4 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI Express x1 | 1 |
| PCI | 1 |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | 12xUSB, 2xHDMI, DVI-I, PS/2 Mouse, PS/2 Keyboard, 2xRJ45 Ethernet, DB9, Audio (in/out/Mic) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 10-90% |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
