System Architecture | |
| Form Factor | Micro ATX |
CPU | |
| СPU Generation/Family | Coffee Lake, Coffee Lake Refresh |
| CPU Support Type | Core i3, Core i5, Core i7, Core i9, Pentium, Celeron |
| Socket | LGA1151 |
Chipset | |
| Chipset | Intel Q370 |
Memory | |
| Form-factor | DDR4 |
| Socket Type | 4xDDR4 DIMM 288pin |
| ECC | No |
| Maximum Memory | 128 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DisplayPort, 2xHDMI, VGA |
Ethernet | |
| Controller Type | Intel i210-AT, Intel i219-LM |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 2 |
| USB v3.x | 10 |
Digital Input-Output | |
| Channels of DIO | 8 |
Audio | |
| Audio Controller | Realtek ALC897 |
Drive interfaces | |
| SATA 3 | 4 |
| RAID Levels | 0, 1, 5, 10 |
| M.2 | 1 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x4 | 2 |
| PCI Express x1 | 2 |
| M.2 | 2 |
| M.2 Form Factor | 2280 M, 2230 E |
Additional Functions | |
| Watchdog timer type | Software |
Connectors | |
| Connectors | PS/2 Keyboard/Mouse, 10xUSB, Display Port, 2xHDMI, DB15 VGA, 2xRJ45 Ethernet, Audio (in/out/Mic) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 244 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
| Humidity | 10-95% |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
