System Architecture | |
| Form Factor | ATX |
CPU | |
| CPU Support Type | Celeron, Core i3, Core i5, Core i7 |
| Socket | LGA1150 |
| Number of CPU | 1 |
Chipset | |
| Chipset | Intel Q87 |
Memory | |
| Form-factor | DDR3 |
| Socket Type | 4xDIMM |
| ECC | No |
| Maximum Memory | 32 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU |
| Interfaces | DVI-D, 2xHDMI, VGA |
Ethernet | |
| Controller Type | Intel i217LM 10/100/1000 Mbps, Intel i211-AT 10/100/1000 Mbps |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 6 |
| RS-232 | 5 |
| RS-232/422/485 | 1 |
| USB Total | 12 |
| USB 2.0 | 10 |
| USB v3.x | 2 |
| LPT | LPT |
Audio | |
| Audio Controller | Intel HD Audio |
Drive interfaces | |
| RAID Levels | 1, 5, 10 |
Extension Slots | |
| Total | 7 |
| PCI Express x16 | 1 |
| PCI Express x4 | 1 |
| PCI | 5 |
Connectors | |
| Connectors | DB9, DVI-D, 2xHDMI, PS/2 Keyboard/Mouse, 2xRJ45 Ethernet, 4xUSB, Audio (in/out/Mic) |
Dimensions and weight | |
| Width | 244 mm |
| Length | 305 mm |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
