Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Panel, Wall VESA 75 |
| Protection Level of Front Side (Panel) | IP65 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 10.2 " |
| Brightness | 350 Cd/m2 |
| Contrast Ratio | 300~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | ARM Cortex A8 TI 3352M |
| Socket | CPU onboard |
Chipset | |
| Chipset | SoC |
Memory | |
| Socket Type | Soldered |
| Default on Board Memory | 0.5 GB |
| Assembly | Fixed on Board |
Graphic | |
| Graphic Controller | Integrated in CPU |
Ethernet | |
| Controller Type | Integrated with Chipset |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
Interfaces | |
| COM Total | 3 |
| RS-232/485 | 1 |
| RS-232/422/485 | 2 |
| USB Total | 2 |
| USB 2.0 | 2 |
LED / Controls | |
| LED | Power LED |
| Controls | On/Off |
Connectors | |
| Connectors | 3xDB9, RJ45, 1xUSB, SD card slot, USB type B |
Power Supply | |
| Supported Types of Power Supply | External power adapter AC/DC |
Software | |
| Operating System Compatibility | MS DOS, Windows CE 6.0, Linux OS |
Dimensions and weight | |
| Width | 279.5 mm |
| Height | 195.5 mm |
| Depth | 39.5 mm |
Standards and Certifications | |
| Certifications | CE, FCC, EN61000-6-2, EN61000-6-4 |
