Construction | |
| Construction Chassis | Metal Chassis with Aluminium Heatsink |
| Mounting Configuration | Desktop |
CPU | |
| Processor Installed | Intel Core i3-6100TE |
Memory | |
| Default on Board Memory | 4 GB |
Drive interfaces | |
| CFast Slots | 1 |
Software | |
| Operating System Installed | Windows Embedded Standard 7 |
Ethernet | |
| 10/100/1000 Mbit/s | 3 |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 6 |
Connectors | |
| Connectors | 2xDB9, DVI-D, HDMI, 3xRJ45, 6xUSB, Mic In, Line Out, DC Input |
Graphic | |
| Interfaces | DVI-D, HDMI |
Dimensions and weight | |
| Width | 90 mm |
| Depth | 185 mm |
| Height | 251 mm |
System Power Input | |
| Input Voltage DC | 24...24 V |
Operating Conditions | |
| Operating Temperature | -5...55 °C |
Standards and Certifications | |
| Certifications | CE, FCC |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
