CPU | |
| Processor Installed | NVIDIA Jetson Xavier NX (6-core ARM v8.2 64-bit CPU, 6MB L2 + 4MB L3) |
| Max CPU frequency | 1.9 GHz |
Memory | |
| Form-factor | DDR4 |
| Socket Type | Soldered |
| Default on Board Memory | 8 GB |
Graphic | |
| Graphic Controller | NVIDIA Volta GPU, 384-Core, 48 Tensor Cores |
Ethernet | |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
Interfaces | |
| USB v3.x | 4 |
Industrial Interfaces | |
| CAN Port | 1 |
Drive interfaces | |
| MicroSD | 1 |
Extension Slots | |
| M.2 | 2 |
Connectors | |
| Connectors | DB37 Female, 4xRJ45 Ethernet, 4xUSB, DC Input, 1xMini USB, Jack 3.5 |
System Power Input | |
| Input Voltage DC | 8...20 V |
| Power Consumption | 90 W |
Software | |
| Operating System Compatibility | Ubuntu |
Dimensions and weight | |
| Width | 140 mm |
| Height | 63.3 mm |
| Depth | 110 mm |
Operating Conditions | |
| Operating Temperature | -20...50 °C |
| Shock | 50G. 11ms |
Standards and Certifications | |
| Certifications | CE, FCC Class B |
| EMI | EN 61000-6-4 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27, IEC 60068-2-64 |
