Specification
Ethernet | |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | 1xRJ-45 |
Interfaces | |
| COM Total | 1 |
| RS-422/485 | 1 |
Supported Protocols | |
| Managment Protocols | IGMPv1/v2, SMTP, BootP, HTTP, Telnet, TCP, UDP, DHCP, DNS, SNMP V1, ARP |
| Security Protocols | ICMP |
LED / Controls | |
| LED | READY LED, TX LED, RX LED, LNK/ACT LED |
| Setup of Operation Mode | Telnet, Via COM-port, Web-interface |
| Controls | 1xReset |
System Power Input | |
| Input Voltage DC | 12...48 V |
Operating Conditions | |
| Operating Temperature | 0...60 °C |
Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Dimensions and weight | |
| Width | 75.2 mm |
| Depth | 22 mm |
| Height | 80 mm |
Standards and Certifications | |
| Certifications | CE, FCC |
| EMI | FCC Part 15 Subpart B Class A, CISPR 32 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 55024, EN 55032 |
| Safety | UL 60950-1, EN 60950-1 |
