Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | 1xRJ-45 |
Interfaces |
| COM Total | 8 |
| RS-232/422/485 | 8 |
Supported Protocols |
| Managment Protocols | SNTP, SMTP, BootP, HTTP, Telnet, TCP, UDP, DHCP, DNS, SNMP V1, Rtelnet, ARP, NTP Client, RFC2217 |
| Security Protocols | ICMP, PPP |
LED / Controls |
| LED | 10/100M LED, READY LED, COM-ports LED |
| Setup of Operation Mode | Telnet, Buttons for Setting up and Displaying Status, Web-interface |
| Controls | On/Off, 1xReset, Control Buttons |
System Power Input |
| Input Voltage AC | 100...240 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | 19" Rackmount |
Dimensions and weight |
| Width | 440 mm |
| Depth | 198 mm |
| Height | 45 mm |
Standards and Certifications |
| Certifications | CE, FCC, EN 60601 |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11, EN 55011 |
| Safety | UL 60950-1, EN 60950-1 |
