Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | 1xSC |
Fiber |
| Number of Optical Ports | 1xSC |
| Type of Fibre Optic | single-mode |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
Supported Protocols |
| Managment Protocols | SNTP, SMTP, BootP, HTTP, Telnet, TCP, UDP, DHCP, DNS, SNMP V1, Rtelnet |
| Security Protocols | ICMP |
LED / Controls |
| LED | READY LED, PWR1, PWR2, COM-ports LED |
| Setup of Operation Mode | Telnet, Via COM-port, Web-interface |
| Controls | 1xReset |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 29 mm |
| Depth | 89.2 mm |
| Height | 118.5 mm |
Standards and Certifications |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Freefall | IEC 60068-2-32 |
| Marine grade | DNV |
| Oil And Gas | Class I Div.2 Groups A, B, C, D, ATEX Zone 2 Ex nC IIC |
| Safety | UL 60950-1, UL 508, EN 60950-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
