Ethernet |
| Total Ethernet | 1 |
| 10/100 Mbit/s | 1 |
| Type 10/100 Mbit/s | 1xRJ-45 |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
Wi-Fi |
| Wi-Fi Standard | 802.11a/b/g/n |
| Quantity of Wi-Fi | 1 |
Supported Protocols |
| Managment Protocols | SNTP, SMTP, SNMPv1/v2c/v3, HTTP, Telnet, TCP, UDP, DHCP, DNS, ICMP |
| Security Protocols | HTTPS, SSH |
LED / Controls |
| LED | Level signal LED, 10/100M LED, WLAN LED, READY LED, COM-ports LED |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
| Controls | 1xReset |
System Power Input |
| Input Voltage DC | 12...48 V |
Operating Conditions |
| Operating Temperature | -40...75 °C |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
Dimensions and weight |
| Width | 77 mm |
| Depth | 26 mm |
| Height | 111 mm |
Standards and Certifications |
| Certifications | CE, FCC |
| EMI | EN 55022 Class A, FCC Part 15 Subpart B Class A |
| EMS | EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11 |
| Safety | UL 60950-1, EN 60950-1 |
