Construction | |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Desktop |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Apollo Lake |
| Processor Installed | Intel Atom E3950 |
| Max CPU frequency | 2 GHz |
Memory | |
| Form-factor | DDR3L |
| Default on Board Memory | 4 GB |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Integrated in Chipset |
| Interfaces | 2xHDMI, VGA |
Ethernet | |
| Total Ethernet | 5 |
| 10/100/1000 Mbit/s | 5 |
Interfaces | |
| COM Total | 1 |
| RS-232 | 1 |
| RS-422/485 | 1 |
Storage Cage | |
| 2.5" Cage External | 2 |
Extension Slots | |
| Mini-PCIe/Mini Card | 3 |
| SIM Card slots | 2 |
LED / Controls | |
| LED | LED Bar |
| Setup of Operation Mode | Remote SMS Control |
Connectors | |
| Connectors | DB15 VGA, 2xHDMI, 1xUSB, M12 |
System Power Input | |
| Input Voltage DC | 24...36 V |
Software | |
| Operating System Compatibility | Windows Embedded Standard 7, Linux OS |
Dimensions and weight | |
| Width | 260 mm |
| Height | 196 mm |
| Depth | 66.5 mm |
Operating Conditions | |
| Operating Temperature | -40...70 °C |
| Vibration | MIL-STD-810G. Method 514.6. Category 4. common carrier US highway truck vibration exposure |
| Shock | MIL-STD-810G. Method 516.6. Procedure I. functional shock=40g |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
