Construction | |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Built-in, Desktop, Wall |
| Type | Fanless |
CPU | |
| СPU Generation/Family | Alder Lake, Raptor Lake |
| Socket | LGA1700 |
Chipset | |
| Chipset | Intel R680E |
Memory | |
| Socket Type | 2xSODIMM |
| ECC | Yes |
| Maximum Memory | 64 GB |
| Assembly | Removable |
Graphic | |
| Graphic Controller | Integrated in CPU, Intel UHD Graphics |
Ethernet | |
| Controller Type | Intel i226-LM |
| Total Ethernet | 2 |
| 2,5 Gbit/s | 2 |
Wi-Fi | |
| Wi-Fi Standard | Yes |
Interfaces | |
| COM Total | 2 |
| RS-232/422/485 | 2 |
| USB Total | 4 |
| USB 2.0 | 2 |
Digital Input-Output | |
| Channels of DIO | 8 |
Digital Input | |
| Isolation DIO | Yes |
Industrial Interfaces | |
| CAN Port | 2 |
Drive interfaces | |
| RAID Levels | 1 |
Storage Cage | |
| Number Of Cage External | 2 |
| 2.5" Cage External | 2 |
Extension Slots | |
| Total | 5 |
| M.2 | 3 |
| Mini-PCIe/Mini Card | 1 |
Connectors | |
| Connectors | 2xDB9, DB15 VGA, HDMI, 2xUSB, DB15 CAN Bus, M12 USB, MicroSD card slot, 2xSIM Card Slot, M12 DC-in, 2xM12 LAN, M8 Audio |
Software | |
| Operating System Compatibility | Linux OS, Windows 10, Windows 11 |
Dimensions and weight | |
| Width | 260 mm |
| Height | 110 mm |
| Depth | 210 mm |
Operating Conditions | |
| Vibration | Vibration (random) - 2g@5~500 Hz (in operation. SSD); Vibration (SSD) - Operating: MIL-STD-810H. Method 514.8C. Procedure 1. Category 4. common carrier US highway truck vibration exposure - Storage: MIL-STD-810H. Method 514.8E. Procedure 1. Category 24. |
| Shock | Operating: MIL-STD-810H. Method 516.8. Procedure I. functional shock=40g; Non-operating: MIL-STD-810H. Method 516.8. Procedure V. crash hazard shock test=75g |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| MIL-STD-810 | MIL-STD-810H Test Method 516.8 Shock, MIL-STD-810H Test Method 514.8 Vibration |
| Rolling Stock | EN 50155, EN 45545 |
| Automotive | e13 Mark |
