Specification
Ethernet | |
| Total Ethernet | 8 |
| 10/100 Mbit/s | 8 |
| Type 10/100 Mbit/s | 8xRJ-45 |
Switch Properties | |
| Managed | No |
| Switch Level | Layer 2 |
System Power Input | |
| Input Voltage DC | 12...48 V |
Construction | |
| Construction Chassis | Plastic Chassis |
| Mounting Configuration | DIN-Rail mount |
Dimensions and weight | |
| Width | 31 mm |
| Depth | 157 mm |
| Height | 113 mm |
Operating Conditions | |
| Operating Temperature | -40...75 °C |
Standards and Certifications | |
| Certifications | CE, WEEE, FCC |
