Construction | |
| Construction Chassis | Metal Chassis, Aluminium Chassis |
CPU | |
| Processor Installed | Intel Celeron N3350, Intel Celeron J3455 |
Memory | |
| Socket Type | 1xSODIMM 204pin |
| Maximum Memory | 8 GB |
Graphic | |
| Graphic Controller | Intel HD Graphics 500 |
Ethernet | |
| Controller Type | Realtek RTL8111E PCIe GbE |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 1 |
| RS-232/422/485 | 1 |
| USB Total | 4 |
Audio | |
| Audio Controller | Realtek ALC888 |
Extension Slots | |
| M.2 | 3 |
Connectors | |
| Connectors | 2xDB9, 2xHDMI, 2xRJ45, 4xUSB, Audio, Display Port |
Power Supply | |
| Output Power | 60 W |
Software | |
| Operating System Compatibility | Linux OS, Windows 10 |
Dimensions and weight | |
| Width | 115 mm |
| Height | 58 mm |
| Depth | 111 mm |
Operating Conditions | |
| Vibration | With SSD: 5Grms. IEC 60068-2-64. Random. 10 ~ 500Hz. 30min/Axis. 3 Axis |
| Shock | With SDD : 55G. IEC 60068-2-27. Half Sine. 11ms. Z Axis |
Standards and Certifications | |
| Certifications | CE, FCC Class A |
| Vibration And Shock | IEC 60068-2-27, IEC 60068-2-64 |
