Construction | |
| Construction Chassis | Heavy-Duty Steel Chassis |
| Mounting Configuration | Wall VESA 100 |
| Protection Level of Chassis | IP66 |
| Type | Fanless |
Display | |
| Display Type | LCD TFT |
| Diagonal | 21.5 " |
| Maximum resolution | 1920x1080 Dots |
| Brightness | 300 Cd/m2 |
| Contrast Ratio | 5000~1 |
Touch Screen | |
| Touch Screen Type | Resistive |
CPU | |
| Processor Installed | Intel Core i5-5350U |
| Max CPU frequency | 2.9 GHz |
Chipset | |
| Chipset | Intel HM76 |
Memory | |
| Form-factor | DDR3L |
| ECC | No |
| Maximum Memory | 8 GB |
Ethernet | |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
Interfaces | |
| COM Total | 2 |
| RS-232 | 2 |
| USB Total | 3 |
| USB 2.0 | 2 |
| USB v3.x | 1 |
Installed drive | |
| Drive Type | SSD |
| 1st Storage Capacity | 120 GB |
Connectors | |
| Connectors | 2xDB9, 2xRJ45 Ethernet, 3xUSB, Display Port |
System Power Input | |
| Input Voltage DC | 9...36 V |
| Input Voltage AC | 115...230 V |
| Power Consumption | 50 W |
Software | |
| Operating System Compatibility | Windows 7, Linux OS, Windows 8.1 |
Dimensions and weight | |
| Width | 568.5 mm |
| Height | 359.5 mm |
| Depth | 114 mm |
Operating Conditions | |
| Operating Temperature | 0...31 °C |
Standards and Certifications | |
| EMI | EN 55022 |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Safety | EN 60950-1 |
