Ethernet |
| Total Ethernet | 2 |
| 10/100 Mbit/s | 2 |
| Type 10/100 Mbit/s | 2xRJ-45 |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 1 |
Antenna characteristics |
| Cellular interfaces | 2G, 3G, 4G |
Extension Slots |
| SIM Card slots | 2, Nano SIM |
Supported Protocols |
| Managment Protocols | SMTP, SNMPv1/v2c/v3, Syslog, Telnet, UDP, DHCP, DDNS, ARP, TCP/IP, SNTP Client |
| Security Protocols | VPN, NAT, Open VPN, IPSec |
Switch Properties |
| Supported technologies | GuaranLink, Dual Isolation |
LED / Controls |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface, ABC-configurator |
Connectors |
| Connectors | Console port RS-232 (4-pin) |
System Power Input |
| Input Voltage DC | 9...36 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 26 mm |
| Depth | 89.1 mm |
| Height | 128.5 mm |
Operating Conditions |
| Operating Temperature | -30...70 °C |
Standards and Certifications |
| EMI | FCC Part 15 Subpart B Class A, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, EN 55024, EN 61000-6-2, EN 61000-6-4, EN 55032 |
| Explosion safety | IECEx, ATEX Zone 2 Group II, UL/cUL Class I Division 2 |
| Freefall | IEC 60068-2-32 |
| Radio | FCC, PTCRB |
| Safety | UL 60950-1, UL 62368-1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
