Ethernet |
| Total Ethernet | 4 |
| 10/100/1000 Mbit/s | 4 |
| Type 10/100/1000 Mbit/s | 4xRJ-45 |
Antenna characteristics |
| Cellular interfaces | 2G, 3G, 4G |
Extension Slots |
| SIM Card slots | 2 |
Additional Functions |
| GPS | GPS |
Supported Protocols |
| Managment Protocols | SNTP, SMTP, HTTP, Telnet, UDP, DHCP, DNS, SNMP, ARP, TCP/IP |
| Security Protocols | VPN, NAT, Firewall, IP Address Filtering, HTTPS, ICMP |
Digital Input |
| Total channels of digital input | 2 |
Digital Output |
| Total channels of digital output | 1 |
| Type | Signal Relay |
| Contact rating of relay (Form A) | 1A@24V DC |
LED / Controls |
| LED | Level signal LED, FAULT LED, READY LED, 2G LED, 3G LED, SIM LED, PWR1, PWR2 |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors |
| Connectors | Console Port RS-232 (RJ-45) |
System Power Input |
| Input Voltage DC | 12...48 V |
| Power Supply Reserve input Voltage DC | 12...48 V |
Construction |
| Construction Chassis | Aluminium Chassis |
| Mounting Configuration | Wall, DIN-Rail mount |
| Protection Level of Chassis | IP30 |
Dimensions and weight |
| Width | 67 mm |
| Depth | 90.5 mm |
| Height | 124 mm |
Operating Conditions |
| Operating Temperature | -30...55 °C |
Standards and Certifications |
| Certifications | CE, FCC |
| EMS | EN 61000-6-2, EN 61000-6-4 |
