Ethernet |
| Total Ethernet | 2 |
| 10/100/1000 Mbit/s | 2 |
| Type 10/100/1000 Mbit/s | 2xRJ-45 |
Interfaces |
| COM Total | 1 |
| RS-232/422/485 | 1 |
| USB Total | 1 |
Antenna characteristics |
| Cellular interfaces | 2G, 3G, 4G |
Extension Slots |
| SIM Card slots | 2, Nano SIM |
Supported Protocols |
| Managment Protocols | DHCP Server/Client, SMTP, SNMPv1/v2c/v3, UDP, Telnet, ARP, TCP/IP |
| Security Protocols | IPSec, NAT, VPN |
Switch Properties |
| Supported technologies | GuaranLink |
LED / Controls |
| Controls | 1xReset |
| Setup of Operation Mode | Telnet, Console Port, Web-interface |
Connectors |
| Connectors | Console Port RS-232 (RJ-45) |
System Power Input |
| Input Voltage DC | 12...48 V |
Construction |
| Construction Chassis | Metal Chassis |
| Mounting Configuration | DIN-Rail mount |
| Protection Level of Chassis | IP40 |
Dimensions and weight |
| Width | 46 mm |
| Depth | 100 mm |
| Height | 125 mm |
Operating Conditions |
| Operating Temperature | -30...70 °C |
| Humidity | 5-95% |
Standards and Certifications |
| EMI | fcc_part_15b_class_a, CISPR 22 Class |
| EMS | IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8 |
| Explosion safety | IECEx, Class I Div 2, ATEX Zone 2 |
| Freefall | IEC 60068-2-32 |
| Radio | rcm |
| Safety | UL 62368-1, en_62368_1 |
| Vibration And Shock | IEC 60068-2-6, IEC 60068-2-27 |
